1. Customizable status LED ring with RGB lights.
2. Touchable button with large 4.3 colored LCD. Built-in Wifi for mobile monitoring (Android/iOS App available).
3. Supports USB On-the-Go function Data log events stored in the inverter.
4.Reserved communication port (RS485, CAN-BUS or RS232) for BMS.
5.Battery independent design. Battery equalization extends lifecycle.
6. User-friendly LCD operation.
7.Enhanced charging power.
8.Built-in anti-dust kit
| Model | MAX II 8000 |
| Rated Power | 8000VA/8000W |
| Parallel Capabilty | Yes, 6 units |
| INPUT | |
| Voltage | 230VAC |
| Selectable Voltage Range | 170-280VAC(For Personal Computers), 90-280VAC(For Home Appl lances) |
| Frequemcy | 50Hz/60Hz(Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230VAC±5% |
| Surge Power | 16000VA |
| Efficiency(Peak) | 93% |
| Transfer Time | 15ms(For Personal Computers) ； 20ms(For Home Appliances) |
| Waveform | Pure SineWave |
| No Load Power Consumption | <70W |
| DC Voltage | 12VDC ± 5%,100W |
| BATTERY | |
| Battery Voltage | 48VDC |
| Floating Charge Voltage | 54VDC |
| Overcharge Protection | 66VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar charger type | MPPT |
| Max PV Array Power | 8000W(4000W*2) |
| MPP Range @operating Voltage | 90~450VDC |
| Max PV Array Open Circuit Voltage | 500VDC |
| Max Solar Charge Current | 150A |
| Max AC Charge Current | 120A |
| Max Charge Current | 150A |
| PHYSICAL | |
| Dimension， DxWxH(mm) | 158.4*502.5*530.8 |
| Net Weight(kgs) | 20kg |
| Communication Interface | USB/RS232/RS485/WIFI/Dry-contact |
| OPERATING ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humid ty(Non-condensing) |
| Operating Temperature | -10C-50°℃ |
| Storage Temperature | -15°C-60°C |
| STANDARD | |
| Compliance Safety | CE |
