- 1. Pure sine wave inverter
- 2. Built-in PWM solar charge controller
- 3. Selectable input voltage range for home appliances and personal computers
- 4. Selectable charging current based on applications
- 5. Configurable AC/Solar input priority via LCD setting
- 6. Compatible to mains voltage or generator power
- 7. Auto restart while AC is recovering
- 8. Overload and short circuit protection
- 9. Smart battery charger design for optimized battery performance
- 10. Cold start function
Model HY1012P HY3022P HY3022PN HY5032VP HY5032VPN HY5032PN Rated power 1000VA/800W 3000VA/2400W3000VA/3000W5000VA/4000W5000VA/5000W5000VA/4000W Parallel Capacity No No No Yes, 9pcs. INPUT Selectable Voltage Range 230VAC Frequency Range 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances) OUTPUT AC Voltage Regulation (Batt. Mode) 230 VAC ± 5% Surge Power 2000VA 6000VA 10000VA 10000VA Efficiency (Peak) 90%~93% Transfer Time 15ms (For Personal Computers) 20ms (For Home Appliances) Waveform Pure sine wave efficiency (peak) 90%-93% 93% BATTERY Battery Voltage 12VDC 24 VDC 48 VDC 48 VDC Floating Charge Voltage 13.5 VDC 27 VDC 54 VDC 54 VDC Overcharge Protection 15 VDC 31 VDC/33 VDC 63VDC 60VDC SOLAR CHARGER & AC CHARGER Solar Charger type PWM Max. PV Array Open Circuit Voltage 50VDC 80VDC 105VDC 105VDC Max. PV Array Power 600W 1200W 2400W 2400W Max. Solar Charge Current 50A 50A 50A 50A Max. AC Charge Current 20A 25A 60A 60A Max. Charge Current 70A 75A 110A 110A PHYSICAL Dimension, D x W x H (mm) 95*240*316 100*272*385 100*300*440 100*300*440 Net Weight (kgs) 5KG 7KG 11KG 11KG ENVIRONMENT Humidity 5% to 95% Relative Humidity (Non-condensing) Operating Temperature -10° C to 50° C Storage Temperature -15° C to 60° C
